DRS-10R V2
5 – 10 kg MTOW
UAVs
360 g
System weight
Reusable
Design
No items found.
DRS-10R V2
Specifications
Weight range
5 – 10 kg MTOW
System weight
360 g
Height/Diameter
140 mm / 100 mm
Parachute Deployment
within 20 - 30 m
Interface
MAVLink, PWM, custom interface
Optional
Geofencing, RC-Trigger
Descent Velocity
2.2 m/s (5 kg) – 3.8 m/s (10 kg)
Impact energy
12 J (5 kg) - 72 J (10 kg)
Certifications
Eligible for testing according to ASTM-F3322 standard and EASA MOC-2511 and MOC-2512.
